80A/120A MPPT Solar Charge Controller Cworth energy

Description

Fabricant : Guangdong Cworth Energy Technology Co., Ltd.

Model	CE-M12048
Maximum Battery Current	120A
Battery Type	Use-Defined/AGM/FLD/LIB
System Voltage	12V/24V/48V DC(Auto detection)
PV Start-up Voltage	25
Maximum Solar input Voltage	200V
PV Array MPPT Voltage Range	25/30/60V-180VDC(For 12V/24V/48V-system)
Maximum Solar panel input Power	12V-1700W
24V-2260W	24V-3400W
48V-4520W	48V-6800W
Charging Algorithm	3-Step
Charging stages	Bulk, Absorption, Float
Operation Temperature Range	-25°C-60°C
Humidity	0%-90%
Maximum Efficiency	＞98%
Net Weight	6.8kg
Product Dimension	340x215x125mm
