12KVA Inverter Cworth energy

Description

Fabricant : Guangdong Cworth Energy Technology Co., Ltd.

Inverter Model	CE-H12K
Rated Output Power(W)	12000W
Nominal DC Input Voltage	48V
Nominal Output Voltage	230Vac
AC Input Normal Voltage	90-280V
Nominal Output Frequency(Hz)	50±0.2Hz/60±0.2Hz(Adjustable)
Peak Efficiency	93%
DC Max Charging/Discharge Current(BAT)	210A/240A
Max. PV Open Circuit Voltage	500V
MPPT Operating Voltage Range	85~450V
Max. Input Current（PV）	27A+27A
Transfer Time (Single unit)	10ms typical (UPS); 20ms typical (Appliances)
Safety Cerification	CE
Operating Temperature Range	-10°C~50°C
Storage Temperature	-15°C~60°C
Net Weight	27kg
Product Dimension	125×525×680mm
